Overview of Smart Citizen Kit
The Smart Citizen Kit is an open-source environmental sensor initiative developed by Fab Lab Barcelona at the Institute for Advanced Architecture of Catalonia (IAAC). This project is designed to empower citizens, communities, and researchers to measure and understand their local environment by deploying affordable and user-friendly sensor devices. These devices collect hyperlocal data on various environmental parameters, including air quality, noise levels, temperature, humidity, and light. The initiative aims to democratize environmental monitoring, making it accessible to all.
Hardware and Sensors
The current generation, Smart Citizen Kit 2.1, features a range of advanced sensors. It measures particulate matter (PM₂.₅ and PM₁₀) using an optical particle counter, nitrogen dioxide (NO₂) and carbon monoxide (CO) through electrochemical sensors, and ozone (O₃), a secondary pollutant formed by sunlight reacting with other emissions. The kit also assesses noise levels in decibels (dBA) using a MEMS microphone, along with standard meteorological parameters such as temperature and humidity, light intensity in lux, and barometric pressure. The kit connects via Wi-Fi, supports local SD card storage, and can be powered by USB or solar panels, all housed in a weather-resistant enclosure designed for 3D printing.
The Smart Citizen Platform
Data collected from the Smart Citizen Kit is aggregated on the Smart Citizen website. This platform features an interactive map that provides a global view of all registered sensors, time-series charts for data visualization, and options for data download in CSV and JSON formats. Additionally, the platform offers RESTful API access for integration and community features that facilitate groups and coordinated measurement campaigns.
Citizen Science Methodology
The Smart Citizen project actively involves communities at all stages, including training and onboarding workshops, collaborative measurement campaigns, and data interpretation support. This citizen-generated data is used for advocacy to challenge official narratives regarding environmental quality, fostering greater community engagement.
Notable Deployments
The Smart Citizen Kit has notable deployments in various locations, including Barcelona, which has the largest concentration of sensors that complement the Sentilo IoT platform. The initiative has also been part of the Making Sense EU Project, where sensors are deployed in cities like Amsterdam and Pristina. Educational institutions, including schools and universities, utilize the kit, contributing to a global community with deployments across Europe, the Americas, Africa, and Asia.
Scientific Validation
Calibration studies indicate that the Smart Citizen Kit provides reasonably accurate screening-level measurements. The kit is intended to complement official monitoring networks by offering hyperlocal coverage rather than replacing them, enhancing the available data for environmental assessments.
Relevance to Smart City Practitioners
The Smart Citizen Kit exemplifies how environmental monitoring can be democratized, showcasing the importance of community engagement in building trust. Open-source hardware facilitates rapid innovation, while bottom-up sensing networks can provide valuable hyperlocal evidence that informs policy and promotes sustainable practices in urban environments.
